INTREPID KM250 (TELE)
Short description
Intrepid KM250 (Tele) compact wheel loader. Universal skidsteer mounting plate, high-quality Belgian manufacturing
Weight (no counterweights): 5400 lbs.
Engine: Yanmar 48hp
Lifting capacity: 5280 lbs.
Lifting capacity, 20″ in front of wheels: 3600 lbs.
Driving speed: 0-12.5 mp/h
Lifting height (hinge point):104 in. / 8.7 ft. (Tele: 140 in. / 11.6 ft)
Specifications
Engine:
25HP Kubota (4 cyl. 4TNV88C)
Service Weight:
5400 lbs. (incl. 3x 77 lbs. counterweights)
Lifting capacity:
5280 lbs. (no counterweights)
Lifting capacity, 20″ in front of wheels:
3600 lbs. (no counterweights)
Driving speed:
0-12.5 mp/h
Lifting height (hinge point):
104 in. / 8.7 ft. (Tele: 140 in. / 11.6 ft)
Length without attachment:
135.4 in. / 11.3 ft.
Width:
65 in.
Driving hydraulics:
4 independent hydraulic wheel-motors
Work hydraulics:
16.5 GPM / 2600 PSI
Full description
The Intrepid KM250 is the largest and most powerful compact wheel loader in the line-up, featuring a 48HP Yanmar engine and a service weight of 5400 lbs. Fitted with a hydraulically locking full-size skidsteer mount, this wheel-loader is the perfect tool-carrier to replace skidsteers on jobsites such as dairy farms, landscape supply stores, rental stores, and green industry projects. The KM250 features an operating capacity of 3560 lbs, allowing you to pick up a pallet of pavers or sod. The KM250 compact wheel loader is manufactured in Belgium by family-run Knikmops and comes in a telescopic version as well.
- Universal mount (full-size skidsteer)
- Two sets of dual action hydr. valve to the front, electr. operable in joystick
- All-function joystick (Bosch-Rexroth)
- Hand throttle to set RPM (if not set, RPM determined by foot pedal)
- Tire size (standard): 19.0/45-17 (65 in. total width)
- LED work lights
- Additional counterweights (mounted as bumper on back)
- Electronic differential lock
- 12V plug to the front, operable as button on joystick
- Back-up alarm
- ROPS/FOPS roof structure
- 1/2” flat-face type hydr. couplers
- 2-speed, max 12.5 mp/h
